AT25F512AN-10SU-2.7

512kbit high speed spi serial flash memory, 5.0V, 5.0mA, SOP8

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.79~0.85 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.79~0.85

PartNumber:: AT25F512AN-10SU-2.7

Brand:: ATMEL Corporation - ATMEL | Pack: SOP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Abby's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-27

From Other Seller

Part Number:AT25F512AN-10SU-2.7
US $0.79 - 0.85
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
QM75DY-H

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT25F512AN-10SU-2.7 is a 512kbit high speed spi serial flash memory. The AT25F512A provides 524,288 bits of serial reprogrammable Flash memory organized as 65,536 words of 8 bits each. The device is optimized for use in many industrial and commercial applications where low－power and low－voltage operation are essential. The AT25F512AN-10SU-2.7 is available in a space－saving 8－lead JEDEC SOIC and 8－lead SAP packages. The AT25F512AN-10SU-2.7 is enabled through the Chip Select pin (CS) and accessed via a three－wire interface consisting of Serial Data Input (SI), Serial Data Output (SO), and Serial Clock (SCK). All write cycles are completely self－timed.

Parametrics

AT25F512AN-10SU-2.7 absolute maximum ratings: (1)Storage Temperature : －65°C to +150°C; (2)Voltage on Any Pin with Respect to Ground: －1.0V to +5.0V; (3)Maximum Operating Voltage : 4.2V; (4)DC Output Current: 5.0 mA; (5)Operating Temperature: －40°C to +85°C.

Features

AT25F512AN-10SU-2.7 features: (1)Serial Peripheral Interface (SPI)Compatible; (2)Supports SPI Modes 0 (0,0)and 3 (1,1): Datasheet Describes 0 Operation; (3)33 MHz Clock Rate; (4)Byte Mode and 128－byte Page Mode for Program Operations; (5)Sector Write Protection; (6)Write Protect (WP)Pin and Write Disable Instructions for both Hardware and Software Data Protection; (7)Self－timed Program Cycle (75 μs/byte typical); (8)Self－timed Sector Erase Cycle (1 second/sector typical); (9)Single Cycle Reprogramming (Erase and Program)for Status Register.
