Product Summary
The G86-730-A2 is one of the first-laptop-GPUs. It is the DirectX 10 capable successor of the Geforece Go 7600/7700 for laptops and technically a higher clocked 8400M GT. The G86-730-A2 supports DirectX 10 and accelerate the H.264-decoding of HD-moives.
Parametrics
G86-730-A2 general specifications: (1)core speed:600MHz; (2)shader speed:1200MHz; (3)memory speed:700MHz; (4)memory bus width:128bit; (5)memory type:GDDR3, GDDR2; (6)Max. amount of memory:512MB; (7)shared memory:no; (8)current consumption:20W; (9)transistors:289 milion; (10)technology:80nm.
Features
G86-730-A2 features: (1)Shader clock frequence 950 MHz; (2)PureVideo technology (H.264, VC-1, MPEG2, WMV9 decoding acceleration); (3)MPEG2, WMV9 decoding acceleration; (4)HDCP-capable; (5)PowerMizer 7.0 power management (dynamic switching between performance and energy economizing); (6)HDR (High Dynamic-Range Lighting); (7)designed for Windows Vista; (8)16x full screen AA; (9)16x AF independent of angles; (10)128-Bit HDR illumination with AA, Dual-Link DVI-D exits for resolutions of TFT up to 2560x1600; (11)PCI-E 16x; (12)OpenGL 2.1; (13)Gigathread technology.
![]() |
