Product Summary
The BCM5696KPB is a multilayer 12-port gigabit ethernet switch.
Features
BCM5696KPB features: (1) 12 10/100/1000－Mbps Ethernet ports with copper or fibre connectivity; (2) All address tables and buffer memory fully integrated on－chip; (3) Support for jumbo frames of up to 9 KB in size; (4) Advanced full－duplex end－to－end flow and congestion control with head－of－line blocking prevention; (5) Support for double 802.1q VLAN tagging and VLAN translation; (6) Hardware－based IP multicast routing and forwarding Support for replication; (7) Equal and weighted cost multipath routing for load balancing; (8) Advanced diagnostic features including JTAG boundary scan and BIST functionality; (9) Low power consumption of 4.65W in a 480－pin PBGA package; (10) Pin－to－pin compatible with the BCM5691.
Diagrams
 |
